Product Description
Arctic Superflex Blue®
Double Conductor Wire
1/0 AWG
Legend:
1/0 AWG 2/C ARCTIC SUPERFLEX BLUE -55C TO 105C VW-1 600 VOLTS OIL RESISTANT
Outside Diameter: 1.13" x 0.58"
We use Arctic Superflex Blue® Double Conductor Cable exclusively in our stock and custom jumper cable systems.
Arctic Superflex Blue® has been tested and successfully used for more than a decade in the harsh environment of Alaska's Arctic North Slope. Flexibility is achieved by combining finely stranded copper construction with a jacket resistant to the abuses of oil, gasoline, acids, chemicals, salt water and sunlight. Arctic Superflex Blue® cables are highly abrasion resistant and can be used in most 600 volt applications.
Features:
- Same Thermoplastic Elastomer jacket as Arctic Ultraflex Blue®
- Fine stranded, flexible copper construction for maximum conductivity
- Cold weather flexibility to -67°F (-55°C)
- High temperature performance to 221°F (105°C)
- Highly abrasion, chemical, water and sunlight resistant
- Parallel bonded construction
- Polarity stripe extruded into jacket
- Tangle resistant
- Built to same UL/AWG specifications as Arctic Ultraflex Blue®
- Exceeds Society of Automotive Engineers (SAE) standards
- Available 8 AWG through 1/0 AWG
- Other sizes available on request
- Custom colors and striping available
- Made in the USA
Applications:
- Battery and jumper cables
- Wind and solar power systems
- Outboard motor leads
- Tow truck booster systems
- ATV and RV power cables
- Uninterrupted power supply systems (UPS)
-55°C to 105°C
Manufactured exclusively by Polar Wire Products
Insulation Properties:
| Insulation Properties | Test Method | Performance |
|---|---|---|
| Specific Gravity (±.02) | ASTM D-792 | 1.30 |
| Durometer Shore 'A' (±.02) INST./15 seconds | ASTM D-2240 | 77/65 |
| Tensile Strength (60 mil) | ASTM D-412 | 2000 |
| Elongation % | ASTM D-412 | 300 |
| Brittle Point (C) | ASTM D-746 | -55°C |
| Oxygen Index % | ASTM D-2863 | 25.0 |
| Oil Aged 18 Hours @ 121°C % Retention of Tensiles % Retention of Elongation | UL Standard UL Standard | 129% 72% |
| Air Aged 7 Days @ 136°C % Retention of Tensiles % Retention of Elongation | ASTM D412-80 ASTM D412-80 | 109% 100% |
| Oil Aged 7 Days @ 60°C % Retention of Tensiles % Retention of Elongation | ASTM D412-80 ASTM D412-80 | 124% 89% |
| VW-1 Flame Test | UL Standard | Pass |
| Product Cold Bend Test | UL Standard | Pass |
| Voltage Rating | UL Standard | 600 |
